LTSFR

Skirting skrue rustfri hærdet

Used outdoor when laying solid wood flooring. The small screw head means that countersinking in the base material is improved, and the screw's design helps preventing wooden floors creaking. Corrosion resistance of the steel is compairable with traditional.

Anvendelsesklasse 2
Anvendelsesklasse 2
Outdoor
Outdoor
EPD
EPD

Produktinformationer

Billeder

Egenskaber

Advantages

  • 6 lobe drive
  • Trim pan head
  • Type 17 point
  • Coarse thread with reverse thread

Applikationer

Support

  • Fodpaneler til træ
  • Sokkel til stål
  • Massivt trægulv til træ

Teknisk data

Product dimensions

ReferenceDimensioner
Best. nr.AndreDimensioner[mm]
DB nr.NOBB nr.Antal pr. kasseVægt[kg]D[mm]L[mm]dₕ[mm]d₁[mm]Ah[mm]hₜ[mm]lg[mm]lp[mm]l-lg[mm]Bit[mm]
LTSFR3.9X35755142055869558417432500.0023.93552.2--23-12TX10
LTSFR3.9X42755152055870558417582500.0023.94252.2--27-15TX10
LTSFR3.9X57755162055871558417622500.0023.95752.2--37-20TX10
LTSFR4.5X70755172055872558417772500.0044.57052.8--46-24TX15
LTSFR4.5X80755182055873558417812500.0054.58052.8--50-30TX15

Certificeringer

Environmental Product Declarations (EPD)
