CLNC0A4
Beklædningssøm 0° plastspole - Rundt hoved, ringformet skaft - rustfri A4
Cladding nail is mainly used for painted facades. The length of the cladding nail is developed to not penetrate the wind shield/protection behind the facade and the flat head covers the opened wood fibre after insertion. The ring shank increase the withdrawal performance and the 60 degree diamond point prevents splitting.
CE mærket
Anvendelsesklasse 3
A4 (rustfri & syrefast)
Severe
EPD
Produktinformationer
Billeder
Egenskaber
Applikationer
Teknisk data
Dimensioner
Product dimensions
| Art. nr. | Item code | DB nr. | NOBB nr. | Fastener dimensions [mm] | Qty/box | Vægt [kg] | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | l | dh | d1 | Ah | ht | lg | lp | tfix | bit | ||||||
| CLNC0A42.8X48 | 75757 | 2056104 | 55837645 | 2.8 | 48 | 5.6 | - | 24.6 | 0.9 | ≥ 32 | 2.5 | 25.6 | - | 1950 | 0.003 |
| CLNC0A42.8X65 | 75758 | 2056105 | 55839518 | 65 | 5.6 | - | 24.6 | 0.9 | ≥ 43 | 2.5 | 42.6 | - | 1300 | 0.005 | |
